Specifications

• General

  Operating Weight

  7.78  ton

  17151.97  lb

  Stabilizer Legs

  Center Pivot

  Backhoe Bucket Capacity

  0.22  m³

  0.29  yd³

  Loader Bucket Capacity

  1.26  m³

  1.65  yd³

• Engine

  Emission

  TIER 3

  Engine model

  Perkins 1104D-44TA

  Perkins 1104D-44TA

  Rated Power

  100  hp / 2,200 rpm

  74.5  kw / 2,200 rpm

  Max. Torque

  41  kgf·m / 1,400 rpm

  296.46  lbf.ft / 1,400 rpm

• Hydraulic System

  Type

  Open center

  Open center

• Tank Capacity

  Fuel tank

  145  ℓ

  38.33  gal

  Engine Oil

  12  ℓ

  3.17  gal

  Hydraulic tank

  100  ℓ

  26.44  gal

• Dimensions

  Overall Length

  6,040  mm

  19'10"  ft.in

  Overall Width

  1,930  mm

  6'4"  ft.in

  Overall Height

  3,710  mm

  12'2"  ft.in

  Ground clearance

  480  mm

  1'7"  ft.in

  Wheelbase

  2,220  mm

  7'3"  ft.in

• Tire

  Front Tires (STD)

  N/A

  N/A

  Rear Tires (STD)

  N/A

  N/A

• Performance

  Breakout force

  -

  Tipping Load (Staight)

  -

  Tipping Load (Full-Turn)

  -

  Cycle time (Raise from Carry Position)

  -

  Cycle time (Lower, empty, foat down)

  -

  Cycle time (Dump, at maximum raise)

  -

  Travel speed (forward, Maximum)

  -

  Travel speed (Reverse, Maximum)

  -

• Operating Range

  Backhoe Digging Height at Maximum

  -

  Backhoe Digging Reach at Maximum

  -

  Backhoe Dumping Height at Maximum

  -

  Loader Hinge Pin Height at Maximum Lift

  -

  Loader Dump Clearance at Maximum lift and 45˚ Discharge

  -
