Specifications

• General

  Type

  Large Excavators

  Operating Weight

  40.36  ton

  88978.58  lb

  Bucket Capacity

  2.03  m³

  2.65  yd³

• Engine

  Emission

  STAGE V

  Engine model

  HYUNDAI DX08

  HYUNDAI DX08

  Rated Power

  340  hp / 1,800 rpm

  253.3  kw / 1,800 rpm

  Max. Torque

  148.9  kgf·m / 1,300 rpm

  1076.65  lbf.ft / 1,300 rpm

• Hydraulic System

  Main Pumps Rated Flow

  2x360  ℓ/min

  2x360  ℓ/min

  Implement Circuit

  -

• Tank Capacity

  Fuel Tank

  600  ℓ

  158.63  gal

  Hydraulic Tank

  247  ℓ

  65.3  gal

  DEF/ ADBLUE Tank

  72  ℓ

  19.04  gal

• Performance

  Swing Speed

  9.9  rpm

  9.9  rpm

  Travel Speed

  5.6  km/h

  3.48  mph

  Max. Traction Force

  34,900  kgf

  15830.37  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  24,960  kgf

  11321.66  lbf

  Arm Digging Force (ISO)

  18,000  kgf

  8164.66  lbf

• Dimensions

  Overall Length

  11,280  mm

  37'0"  ft.in

  Overall Width

  2,990  mm

  9'10"  ft.in

  Overall Height

  3,460  mm

  11'4"  ft.in

  Tail Swing Radius

  3,530  mm

  11'7"  ft.in

  Tumbler Distance

  4,230  mm

  13'11"  ft.in

  Ground Clearance

  1,313  mm

  4'4"  ft.in

• Operating Range

  Boom Length

  6,500  mm

  21'4"  ft.in

  Arm Length

  3,200  mm

  10'6"  ft.in

  Max. Digging Reach

  11,115  mm

  36'6"  ft.in

  Max. Digging Depth

  7,400  mm

  24'3"  ft.in

  Max. Digging Height

  10,280  mm

  33'9"  ft.in

  Max. Dumping Height

  7,305  mm

  23'12"  ft.in

  Min. Swing Radius

  4,450  mm

  14'7"  ft.in
