Specifications

• General

  Operating Weight

  15.3  ton

  33730.73  lb

  Blade Capacity

  4.18  m³

  5.47  yd³

• Engine

  Emission

  STAGE V

  Engine model

  Perkins 1204J

  Perkins 1204J

  Rated Power

  157  hp / 2,200 rpm

  116.97  kw / 2,200 rpm

  Max. Torque

  72.399  kgf·m / 1,400 rpm

  523.5  lbf.ft / 1,400 rpm

• Driveline

• Hydraulic System

  Type

  VARIABLE PISTON

  VARIABLE PISTON

  System Pressure

  270  kgf/cm²

  3840.32  psi

  Implement Maximum Flow Rate

  132  ℓ/min

  34.9  gal/min

• Tank Capacity

  Fuel tank

  267  ℓ

  70.59  gal

  Engine Oil

  12.35  ℓ

  3.27  gal

  Hydraulic tank

  100  ℓ

  26.44  gal

• Dimensions

  Blade Width

  3,370  mm

  11'1"  ft.in

  Overall Height

  3,180  mm

  10'5"  ft.in

  Overall Length

  5,035  mm

  16'6"  ft.in

  Ground clearance

  355  mm

  1'2"  ft.in

  Digging Depth

  405  mm

  1'4"  ft.in

  Overall Track Length

  3,690  mm

  12'1"  ft.in

  Track Gauge

  2,000  mm

  6'7"  ft.in

  Maximum Blade Angle

  25º

  25º
