Specifications

• General

  Operating Weight

  7.5  ton

  16534.67  lb

  Stabilizer Legs

  Center Pivot

  Backhoe Bucket Capacity

  0.23  m³

  0.3  yd³

  Loader Bucket Capacity

  1.0  m³

  1.31  yd³

• Engine

  Emission

  TIER 4f

  Engine model

  HYUNDAI DN03-LEL40

  HYUNDAI DN03-LEL40

  Rated Power

  100  kW / 2,200 rpm

  134  hp / 2,200 rpm

  Max. Torque

  42  kgf·m / 1,350 rpm

  303.69  lbf.ft / 1,350 rpm

• Hydraulic System

  Type

  Open center

  Open center

• Tank Capacity

  Fuel tank

  130  ℓ

  34.37  gal

  Engine Oil

  12.6  ℓ

  3.33  gal

  Hydraulic tank

  50  ℓ

  13.22  gal

• Dimensions

  Overall Length

  7,080  mm

  23'3"  ft.in

  Overall Width

  2,205  mm

  7'3"  ft.in

  Overall Height

  3,680  mm

  12'1"  ft.in

  Ground clearance

  261  mm

  0'10"  ft.in

  Wheelbase

  2,200  mm

  7'3"  ft.in

• Tire

  Front Tires (STD)

  12.5/80-18,12PR (4WD)

  12.5/80-18,12PR (4WD)

  Rear Tires (STD)

  16.9-28,12PR

  16.9-28,12PR

• Performance

  Breakout force

  -

  Tipping Load (Staight)

  -

  Tipping Load (Full-Turn)

  -

  Cycle time (Raise from Carry Position)

  -

  Cycle time (Lower, empty, foat down)

  -

  Cycle time (Dump, at maximum raise)

  -

  Travel speed (forward, Maximum)

  34  km/h

  21.13  mph

  Travel speed (Reverse, Maximum)

  19  km/h

  11.81  mph

• Operating Range

  Backhoe Digging Height at Maximum

  5,500  mm

  18'1"  ft.in

  Backhoe Digging Reach at Maximum

  5,830  mm

  19'2"  ft.in

  Backhoe Dumping Height at Maximum

  3,585  mm

  11'9"  ft.in

  Loader Hinge Pin Height at Maximum Lift

  3,450  mm

  11'4"  ft.in

  Loader Dump Clearance at Maximum lift and 45˚ Discharge

  2,710  mm

  8'11"  ft.in
