Operating Weight
10.7  ton
Emission
STAGE V
Rated Power
122  hp / 2,200 rpm
Blade Width
2,770  mm
General
Operating Weight
10.7  ton
Blade Capacity
2.58  m³
Engine
Emission
STAGE V
Engine model
G2 DM03-LED00
Rated Power
122  hp / 2,200 rpm
Max. Torque
54.045  kgf·m / 1,400 rpm
Driveline
Hydraulic System
Type
VARIABLE DISPLACEMENT
System Pressure
265  kgf/cm²
Implement Maximum Flow Rate
103.5  ℓ/min
Tank Capacity
Fuel tank
190  ℓ
Engine Oil
14.6  ℓ
Hydraulic tank
74  ℓ
Dimensions
Blade Width
2,770  mm
Overall Height
2,900  mm
Overall Length
5,618  mm5,618(4,739)mm
Ground clearance
200  mm
Digging Depth
466  mm
Overall Track Length
3,567  mm
Track Gauge
1,890  mm
Maximum Blade Angle
25º
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
