Specifications

• General

  Type

  Wide-body Dump Trucks

  Operating Weight

  30  ton

  66138.69  lb

  Heaped

  36  m³

  47.08  yd³

  Rated Payload

  60  ton

  132277.38  lb

• Engine

  Emission

  TIER 3

  Engine model

  Weichai 460 horse power

  Weichai 460 horse power

  Rated Power

  460  hp / 2,100 rpm

  342.7  kw / 2,100 rpm

  Max. Torque

  204  kgf·m / 1,600 rpm

  1475.06  lbf.ft / 1,600 rpm

• Hydraulic System

  Main pumps rated flow

  220  ℓ/min

  58.16  gal/min

  Implement circuit

  255  kgf/cm²

  3626.97  psi

• Tank Capacity

  Fuel tank

  500  ℓ

  13.22  gal

  Engine Oil

  27  ℓ

  7.14  gal

  Hydraulic tank

  200  ℓ

  52.88  gal

• Performance

  Travel speed (forward, Maximum)

  40  km/h

  24.85  mph

  Travel speed (Reverse, Maximum)

  5  km/h

  3.11  mph

• Dimensions

  Overall length

  9,160  mm

  30'1"  ft.in

  Overall height

  3,770  mm

  12'4"  ft.in

  Overall width

  3,750  mm

  12'4"  ft.in

  Inner turning radius

  7,550  mm

  24'9"  ft.in

  Outer turning radius

  11,250  mm

  36'11"  ft.in

  Outer wheel turning radius

  10,450  mm

  34'3"  ft.in
