Specifications

• General

  Type

  Wide-body Dump Trucks

  Operating Weight

  35  ton

  77161.81  lb

  Heaped

  44  m³

  57.54  yd³

  Rated Payload

  70  ton

  154323.61  lb

• Engine

  Emission

  TIER 3

  Engine model

  Weichai 530 horse power

  Weichai 530 horse power

  Rated Power

  530  hp / 2,100 rpm

  394.85  kw / 2,100 rpm

  Max. Torque

  234.5  kgf·m / 1,600 rpm

  1695.6  lbf.ft / 1,600 rpm

• Hydraulic System

  Main pumps rated flow

  250  ℓ/min

  66.09  gal/min

  Implement circuit

  255  kgf/cm²

  3626.97  psi

• Tank Capacity

  Fuel tank

  600  ℓ

  158.63  gal

  Engine Oil

  27  ℓ

  7.14  gal

  Hydraulic tank

  200  ℓ

  52.88  gal

• Performance

  Travel speed (forward, Maximum)

  40  km/h

  24.85  mph

  Travel speed (Reverse, Maximum)

  4  km/h

  2.49  mph

• Dimensions

  Overall length

  9,360  mm

  30'9"  ft.in

  Overall height

  4,160  mm

  13'8"  ft.in

  Overall width

  3,750  mm

  12'4"  ft.in

  Inner turning radius

  8,000  mm

  26'3"  ft.in

  Outer turning radius

  12,000  mm

  39'4"  ft.in

  Outer wheel turning radius

  11,000  mm

  36'1"  ft.in
