Specifications

• General

  Type

  Skid Steer Loaders

  Operating Weight

  3,720  kg

  8201.2  lb

  Rated Operating Capacity

  1,220  kg (50% Tipping Load)

  2689.64  lb (50% Tipping Load)

• Engine

  Emission

  STAGE V

  Engine model

  4HTI4 / 4HTI5

  4HTI4 / 4HTI5

  Rated Power

  73.6  hp / 2,400 rpm

  54.83  kw / 2,400 rpm

  Max. Torque

  27.92  kgf·m / 1,500 rpm

  201.88  lbf.ft / 1,500 rpm

• Hydraulic System

  Hydraulic Flow Rate

  82.9  ℓ/min

  21.92  gal/min

  Hydraulic Pressure

  234.95  kgf/cm²

  3341.79  psi

  Hydraulic Flow Rate (high-Flow)

  128.8  ℓ/min

  34.05  gal/min

  Hydraulic Pressure (high-Flow)

  152.96  kgf/cm²

  2175.61  psi

• Tank Capacity

  Fuel tank

  100  ℓ

  26.44  gal

  Engine Oil

  9  ℓ

  2.38  gal

  Hydraulic tank

  38  ℓ

  10.05  gal

• Performance

  Breakout force (Bucket)

  2,500  kgf

  1133.98  lbf

  Breakout force (Lift Arm)

  2,275  kgf

  1031.92  lbf

  Tipping Load

  2,440  kg

  5379.28  lb

  Lift Arm Path

  Vertical Lift Path

• Dimensions

  Overall Length

  3,675  mm

  12'1"  ft.in

  Overall Width

  1,820  mm

  5'12"  ft.in

  Overall Height

  4,068  mm

  13'4"  ft.in

  Ground clearance

  195  mm

  0'8"  ft.in

  Wheelbase

  1,200  mm

  3'11"  ft.in

• Power Train / Undercarriage

  Travel speed (1-Speed)

  13.6  km/h

  8.45  mph

  Travel speed (2-Speed, Low)

  11.5  km/h

  7.15  mph

  Travel speed (2-Speed, High)

  19.8  km/h

  12.3  mph

  Tires Type

  12-16.5 12PR

  12-16.5 12PR

• Operating Range

  Hinge Pin Height at Maximum Lift

  3,215  mm

  10'7"  ft.in

  Reach at Maximum Lift

  949  mm

  3'1"  ft.in
