Specifications

• General

  Type

  Skid Steer Loaders

  Operating Weight

  3,355  kg

  7396.51  lb

  Rated Operating Capacity

  860  kg (50% Tipping Load)

  1895.98  lb (50% Tipping Load)

• Engine

  Emission

  TIER 3

  Engine model

  Kubota V3307-T

  Kubota V3307-T

  Rated Power

  74.3  hp / 2,400 rpm

  55.35  kw / 2,400 rpm

  Max. Torque

  27  kgf·m / 1,500 rpm

  195.23  lbf.ft / 1,500 rpm

• Hydraulic System

  Hydraulic Flow Rate

  63.9  ℓ/min

  16.89  gal/min

  Hydraulic Pressure

  175  kgf/cm²

  2489.09  psi

  Hydraulic Flow Rate (high-Flow)

  110  ℓ/min

  29.08  gal/min

  Hydraulic Pressure (high-Flow)

  150  kgf/cm²

  2133.51  psi

• Tank Capacity

  Fuel tank

  83  ℓ

  21.94  gal

  Engine Oil

  11.2  ℓ

  2.96  gal

  Hydraulic tank

  57  ℓ

  15.07  gal

• Performance

  Tipping Load

  1,718  kg

  3787.54  lb

  Lift Arm Path

  Radial Lift Path

• Dimensions

  Overall Length

  3,470  mm

  11'5"  ft.in

  Overall Width

  1,894  mm

  6'3"  ft.in

  Overall Height

  2,000  mm

  6'7"  ft.in

  Ground clearance

  205  mm

  0'8"  ft.in

  Wheelbase

  1,100  mm

  3'7"  ft.in

• Power Train / Undercarriage

  Travel speed (1-Speed)

  11.4  km/h

  7.08  mph

  Tires Type

  12-16.5,12PR

  12-16.5,12PR

• Operating Range

  Hinge Pin Height at Maximum Lift

  3,075  mm

  10'1"  ft.in

  Reach at Maximum Lift

  510  mm

  1'8"  ft.in
