Specifications

• General

  Type

  Compact Track Loaders

  Operating Weight

  5,799  kg

  12784.61  lb

  Rated Operating Capacity

  1,727  kg (35% Tipping Load)

  3807.38  lb (35% Tipping Load)

• Engine

  Emission

  TIER 4 FINAL

  Engine model

  HYUNDAI D34

  HYUNDAI D34

  Rated Power

  115.3  hp / 2,400 rpm

  85.9  kw / 2,400 rpm

  Max. Torque

  46.9  kgf·m / 1,400 rpm

  339.12  lbf.ft / 1,400 rpm

• Hydraulic System

  Hydraulic Flow Rate

  86  ℓ/min

  22.74  gal/min

  Hydraulic Pressure

  234.54  kgf/cm²

  3335.95  psi

  Hydraulic Flow Rate (high-Flow)

  151.2  ℓ/min

  39.97  gal/min

  Hydraulic Pressure (high-Flow)

  285.52  kgf/cm²

  4061.06  psi

• Tank Capacity

  Fuel tank

  110  ℓ

  29.08  gal

  Engine Oil

  14.6  ℓ

  3.86  gal

  Hydraulic tank

  40  ℓ

  10.58  gal

• Performance

  Breakout force (Bucket)

  3,016  kgf

  1368.03  lbf

  Breakout force (Lift Arm)

  3,067  kgf

  1391.17  lbf

  Tipping Load

  4,933  kg

  10875.41  lb

  Lift Arm Path

  Vertical Lift Path

• Dimensions

  Overall Length

  4,210  mm

  13'10"  ft.in

  Overall Width

  2,001  mm

  6'7"  ft.in

  Overall Height

  2,133  mm

  6'12"  ft.in

  Ground clearance

  247  mm

  0'10"  ft.in

  Wheelbase

  -

  Track Tread

  1,551  mm

  5'1"  ft.in

• Power Train / Undercarriage

  Travel speed (1-Speed)

  -

  Travel speed (2-Speed, Low)

  9.8  km/h

  6.09  mph

  Travel speed (2-Speed, High)

  14.8  km/h

  9.2  mph

  Track Width

  450  mm

  1'6"  ft.in

  Ground pressure

  0.401  kgf/cm²

  5.7  psi

  Tires Type

  -

• Operating Range

  Hinge Pin Height at Maximum Lift

  3,280  mm

  10'9"  ft.in

  Reach at Maximum Lift

  1,175  mm

  3'10"  ft.in
