HS80V
-
Type
Skid Steer Loaders
-
Rated Operating Capacity
885 kg
(50% Tipping Load)
-
Emission
STAGE V
-
Rated Power
66.4 hp / 2,400 rpm
-
Lift Arm Path
Vertical Lift Path
- Catalog
Specifications
-
General
Type
Skid Steer Loaders
Operating Weight
3,256 kg
Rated Operating Capacity
885 kg (50% Tipping Load)
-
Engine
Emission
STAGE V
Engine model
4HT4 / 4HT5
Rated Power
66.4 hp / 2,400 rpm
Max. Torque
24.16 kgf·m / 1,700 rpm
-
Hydraulic System
Hydraulic Flow Rate
64 ℓ/min
Hydraulic Pressure
223.59 kgf/cm²
-
Tank Capacity
Fuel tank
94 ℓ
Engine Oil
9 ℓ
Hydraulic tank
31 ℓ
-
Performance
Breakout force (Bucket)
1,710 kgf
Breakout force (Lift Arm)
1,745 kgf
Tipping Load
1,770 kg
Lift Arm Path
Vertical Lift Path
-
Dimensions
Overall Length
3,587 mm
Overall Width
1,690 mm
Overall Height
3,902 mm
Ground clearance
145 mm
Wheelbase
1,080 mm
-
Power Train / Undercarriage
Travel speed (1-Speed)
11.9 km/h
Tires Type
10-16.5 8PR
-
Operating Range
Hinge Pin Height at Maximum Lift
3,057 mm
Reach at Maximum Lift
950 mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color. - This product has images of similar models for reference, so there may be slight size differences compared to the actual product.
