Specifications

• General

  Type

  Compact Track Loaders

  Operating Weight

  4,564  kg

  10061.9  lb

  Rated Operating Capacity

  1,043  kg (35% Tipping Load)

  2299.42  lb (35% Tipping Load)

• Engine

  Emission

  STAGE V

  Engine model

  Hyundai Model 4HTI4 / 4HTI5

  Hyundai Model 4HTI4 / 4HTI5

  Rated Power

  73.6  hp / 2,400 rpm

  54.83  kw / 2,400 rpm

  Max. Torque

  28  kgf·m / 1,500 rpm

  202.46  lbf.ft / 1,500 rpm

• Hydraulic System

  Hydraulic Flow Rate

  82.9  ℓ/min

  21.92  gal/min

  Hydraulic Pressure

  234.95  kgf/cm²

  3341.79  psi

  Hydraulic Flow Rate (high-Flow)

  128.8  ℓ/min

  34.05  gal/min

  Hydraulic Pressure (high-Flow)

  152.96  kgf/cm²

  2175.61  psi

• Tank Capacity

  Fuel tank

  100  ℓ

  26.44  gal

  Engine Oil

  9  ℓ

  2.38  gal

  Hydraulic tank

  38  ℓ

  10.05  gal

• Performance

  Breakout force (Bucket)

  2,500  kgf

  1133.98  lbf

  Breakout force (Lift Arm)

  2,275  kgf

  1031.92  lbf

  Tipping Load

  2,980  kg

  6569.78  lb

  Lift Arm Path

  Vertical Lift Path

• Dimensions

  Overall Length

  3,654  mm

  11'12"  ft.in

  Overall Width

  1,794  mm

  5'11"  ft.in

  Overall Height

  2,078  mm

  6'10"  ft.in

  Ground clearance

  230  mm

  0'9"  ft.in

  Track Tread

  1,400  mm

  4'7"  ft.in

• Power Train / Undercarriage

  Travel speed (2-Speed, Low)

  7.5  km/h

  4.66  mph

  Travel speed (2-Speed, High)

  11.5  km/h

  7.15  mph

  Track Width

  400  mm

  1'4"  ft.in

  Ground pressure

  0.406  kgf/cm²

  5.77  psi

• Operating Range

  Hinge Pin Height at Maximum Lift

  3,310  mm

  10'10"  ft.in

  Reach at Maximum Lift

  1,098  mm

  3'7"  ft.in
