HSL650-7
-
Type
Skid Steer Loaders
-
Rated Operating Capacity
650 kg
(50% Tipping Load)
-
Emission
~TIER 2
-
Rated Power
24.2 kW / 2,500 rpm
-
Lift Arm Path
Radial Lift Path
- Catalog
Specifications
-
General
Type
Skid Steer Loaders
Operating Weight
2,690 kg
Rated Operating Capacity
650 kg (50% Tipping Load)
-
Engine
Emission
~TIER 2
Engine model
Kubota V2203M
Rated Power
24.2 kW / 2,500 rpm
Max. Torque
14 kgf·m / 1,600 rpm
-
Hydraulic System
Hydraulic Flow Rate
69.3 ℓ/min
Hydraulic Pressure
178.42 kgf/cm²
-
Tank Capacity
Fuel tank
60 ℓ
Engine Oil
7.6 ℓ
Hydraulic tank
38 ℓ
-
Performance
Tipping Load
1,310 kg
Lift Arm Path
Radial Lift Path
-
Dimensions
Overall Length
3,270 mm
Overall Width
1,625 mm
Overall Height
1,965 mm
Ground clearance
183 mm
Wheelbase
990 mm
-
Power Train / Undercarriage
Travel speed (1-Speed)
11.8 km/h
Tires Type
10-16.5,6PR
-
Operating Range
Hinge Pin Height at Maximum Lift
2,915 mm
Reach at Maximum Lift
550 mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color. - This product has images of similar models for reference, so there may be slight size differences compared to the actual product.
