Special Equipments
HX260FC
-
Type
Others
-
Operating Weight
32.9 ton
-
Emission
TIER 3
-
Rated Power
190 hp / 2,200 rpm
- Catalog
Specifications
-
General
Type
Others
Operating Weight
32.9 ton
-
Engine
Emission
TIER 3
Engine model
HYUNDAI / HE6.7
Rated Power
190 hp / 2,200 rpm
Max. Torque
94.7 kgf·m / 1,400 rpm
-
Hydraulic System
Main Pumps Rated Flow
2x247 ℓ/min
Implement Circuit
350 kgf/cm²
-
Tank Capacity
Fuel Tank
450 ℓ
Hydraulic Tank
160 ℓ
DEF/ ADBLUE Tank
- not applied
-
Performance
Swing Speed
10.9 rpm
Travel Speed
5.6 km/h
Max. Traction Force
22,193 kgf
Max. Gradeability
35 deg
-
Dimensions
Overall Length
10,050 mm
Overall Width
3,470 mm
Overall Height
3,390 mm
Tail Swing Radius
3,085 mm
Tumbler Distance
4,030 mm
Ground Clearance
765 mm
-
Operating Range
Boom Length
5,850 mm
Arm Length
3,050 mm
Max. Digging Reach
8,740 mm
Max. Digging Depth
3,885 mm
Max. Digging Height
9,610 mm
Max. Dumping Height
7,150 mm
Min. Swing Radius
3,450 mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
