Special Equipments
HX300FC
-
Type
Others
-
Operating Weight
35.6 ton
-
Emission
TIER 3
-
Rated Power
220 hp / 2,000 rpm
- Catalog
Specifications
-
General
Type
Others
Operating Weight
35.6 ton
-
Engine
Emission
TIER 3
Engine model
HYUNDAI / HE6.7
Rated Power
220 hp / 2,000 rpm
Max. Torque
96.8 kgf·m / 1,400 rpm
-
Hydraulic System
Main Pumps Rated Flow
2x277 ℓ/min
Implement Circuit
350 kgf/cm²
-
Tank Capacity
Fuel Tank
500 ℓ
Hydraulic Tank
190 ℓ
DEF/ ADBLUE Tank
- not applied
-
Performance
Swing Speed
11.56 rpm
Travel Speed
5.9 km/h
Max. Traction Force
27,405 kgf
Max. Gradeability
35 deg
-
Dimensions
Overall Length
10,810 mm
Overall Width
3,470 mm
Overall Height
3,590 mm
Tail Swing Radius
3,345 mm
Tumbler Distance
4,030 mm
Ground Clearance
765 mm
-
Operating Range
Boom Length
6,250 mm
Arm Length
3,050 mm
Max. Digging Reach
9,190 mm
Max. Digging Depth
4,115 mm
Max. Digging Height
10,480 mm
Max. Dumping Height
7,335 mm
Min. Swing Radius
4,095 mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
