Specifications

• General

  Type

  Demolitions

  Operating Weight

  48.6  ton

  107144.68  lb

  Bucket Capacity

  -

• Engine

  Emission

  ~TIER 2

  Engine model

  HYUNDAI D6AC-C

  HYUNDAI D6AC-C

  Rated Power

  276  kW / 1,900 rpm

  370  hp / 1,900 rpm

  Max. Torque

  120  kgf·m / 1,400 rpm

  867.68  lbf.ft / 1,400 rpm

• Hydraulic System

  Main Pumps Rated Flow

  2x280  ℓ/min

  2x280  ℓ/min

  Implement Circuit

  330  kgf/cm²

  4693.72  psi

• Tank Capacity

  Fuel Tank

  550  ℓ

  145.41  gal

  Hydraulic Tank

  210  ℓ

  55.52  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  10  rpm

  10  rpm

  Travel Speed

  5  km/h

  3.11  mph

  Max. Traction Force

  32,000  kgf

  14514.95  lbf

  Max. Gradeability

  35  deg

  35  deg

• Dimensions

  Overall Length

  14,520  mm

  47'8"  ft.in

  Overall Width

  3,340  mm

  10'11"  ft.in

  Overall Height

  3,610  mm

  11'10"  ft.in

  Tail Swing Radius

  -

  Tumbler Distance

  -

  Ground Clearance

  -

• Operating Range

  Boom Length

  -

  Arm Length

  -

  Max. Digging Reach

  -

  Max. Digging Depth

  -

  Max. Digging Height

  -

  Max. Dumping Height

  -

  Min. Swing Radius

  -
