Special Equipments
Type
Material Handlers
Operating Weight
26.1  ton
Emission
TIER 4 FINAL
Rated Power
178  hp / 2,000 rpm
General
Type
Material Handlers
Operating Weight
26.1  ton
Engine
Emission
TIER 4 FINAL
Engine model
CUMMINS QSB6.7
Rated Power
178  hp / 2,000 rpm
Max. Torque
85.7  kgf·m / 1,500 rpm
Hydraulic System
Main Pumps Rated Flow
2x234  ℓ/min
Implement Circuit
350  kgf/cm²
Tank Capacity
Fuel Tank
310  ℓ
Hydraulic Tank
165  ℓ
DEF/ ADBLUE Tank
27  ℓ
Performance
Swing Speed
9.7  rpm
Travel Speed
35  km/h
Max. Traction Force
11,600  kgf
Max. Gradeability
33  deg
Dimensions
Overall Length
9,730  mm
Overall Width
3,245  mm
Overall Height
2,530  mm
Tail Swing Radius
2,913  mm
Tumbler Distance
2,800  mm
Ground Clearance
353  mm
Operating Range
Boom Length
6,500  mm
Arm Length
4,500  mm
Max. Digging Reach
10,700  mm
Max. Digging Depth
4,700  mm
Max. Digging Height
12,000  mm
Max. Dumping Height
9,880  mm
Min. Swing Radius
3,000  mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
