Specifications

• General

  Type

  Others

  Operating Weight

  40.4  ton

  89066.77  lb

• Engine

  Emission

  TIER 4 FINAL

  Engine model

  CUMMINS QSB6.7

  CUMMINS QSB6.7

  Rated Power

  256  hp / 2,000 rpm

  190.72  kw / 2,000 rpm

  Max. Torque

  100.9  kgf·m / 1,500 rpm

  729.58  lbf.ft / 1,500 rpm

• Hydraulic System

  Main Pumps Rated Flow

  2x273  ℓ/min

  2x273  ℓ/min

  Implement Circuit

  350  kgf/cm²

  4978.19  psi

• Tank Capacity

  Fuel Tank

  500  ℓ

  132.19  gal

  Hydraulic Tank

  190  ℓ

  50.23  gal

  DEF/ ADBLUE Tank

  43  ℓ

  11.37  gal

• Performance

  Swing Speed

  10.2  rpm

  10.2  rpm

  Travel Speed

  5.9  km/h

  3.67  mph

  Max. Traction Force

  26,500  kgf

  12020.2  lbf

  Max. Gradeability

  35  deg

  35  deg

• Dimensions

  Overall Length

  17,700  mm

  58'1"  ft.in

  Overall Width

  3,100  mm

  10'2"  ft.in

  Overall Height

  3,200  mm

  10'6"  ft.in

  Tail Swing Radius

  3,120  mm

  10'3"  ft.in

  Tumbler Distance

  4,030  mm

  13'3"  ft.in

  Ground Clearance

  500  mm

  1'8"  ft.in

• Operating Range

  Boom Length

  6,250  mm

  20'6"  ft.in

  Arm Length

  - 가변

  Max. Digging Reach

  11,200  mm

  36'9"  ft.in

  Max. Digging Depth

  25,000  mm

  82'0"  ft.in

  Max. Dumping Height

  5,100  mm

  16'9"  ft.in

  Min. Swing Radius

  9,000  mm

  29'6"  ft.in
