Special Equipments
R210W-9 MH
-
Type
Material Handlers
-
Operating Weight
25.7 ton
-
Emission
TIER 3
-
Rated Power
165 hp / 1,900 rpm
- Catalog
Specifications
-
General
Type
Material Handlers
Operating Weight
25.7 ton
-
Engine
Emission
TIER 3
Engine model
HYUNDAI HE 6.7
Rated Power
165 hp / 1,900 rpm
Max. Torque
81.4 kgf·m / 1,400 rpm
-
Hydraulic System
Main Pumps Rated Flow
2x228 ℓ/min
Implement Circuit
350 kgf/cm²
-
Tank Capacity
Fuel Tank
310 ℓ
Hydraulic Tank
165 ℓ
DEF/ ADBLUE Tank
- not applied
-
Performance
Swing Speed
10.3 rpm
Travel Speed
35 km/h
Max. Traction Force
11,900 kgf
Max. Gradeability
31.5 deg
-
Dimensions
Overall Length
9,600 mm
Overall Width
3,720 mm
Overall Height
2,530 mm
Tail Swing Radius
2,768 mm
Tumbler Distance
2,800 mm
Ground Clearance
345 mm
-
Operating Range
Boom Length
6,500 mm
Arm Length
4,500 mm
Max. Digging Reach
11,000 mm
Max. Digging Depth
4,710 mm
Max. Digging Height
12,650 mm
Max. Dumping Height
9,880 mm
Min. Swing Radius
3,000 mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
