Specifications

• General

  Operating Weight

  19.5  ton

  42990.15  lb

• Engine

  Emission

  TIER 3

  Engine Model

  QSL8.9

  QSL8.9

  Rated Power

  160kW/2,200rpm

  160kW/2,200rpm

  Max. Torque

  1200Nm/1,500rpm

  1200Nm/1,500rpm

• Hydraulic System

  Main Pumps Rated Flow

  167  ℓ/min

  44.15  gal/min

  Implement Circuit

  235  kgf/cm²

  3342.5  psi

• Tank Capacity

  Fuel tank

  475  ℓ

  125.58  gal

  Engine Oil

  20  ℓ

  5.29  gal

  Hydraulic tank

  100  ℓ

  26.44  gal

• Performance

  Travel Speed (Forward, Maximum)

  48.86  km/h

  30.36  mph

  Travel Speed (Reverse, Maximum)

  48.86  km/h

  30.36  mph

• Dimensions

  Overall Length

  9,850  mm

  32'4"  ft.in

  Overall Width

  3,966  mm

  13'0"  ft.in

  Overall Height

  3,650  mm

  11'12"  ft.in

  Ground clearance

  540  mm

  1'9"  ft.in

  Moldboard

  3,966  mm

  13'0"  ft.in

  Length of Between Counterweight to Ripper

  10,307  mm

  33'10"  ft.in

  Height to Top of ROPS Frame

  3,650  mm

  11'12"  ft.in
