Specifications

• General

  Operating Weight

  28  ton

  61729.44  lb

• Engine

  Emission

  TIER 3

  Engine Model

  QSM11

  QSM11

  Rated Power

  330kW/2,100rpm

  330kW/2,100rpm

  Max. Torque

  1,674Nm/1,400rpm

  1,674Nm/1,400rpm

• Hydraulic System

  Main Pumps Rated Flow

  155  ℓ/min

  40.98  gal/min

  Implement Circuit

  255  kgf/cm²

  3626.97  psi

• Tank Capacity

  Fuel tank

  541  ℓ

  143.03  gal

  Engine Oil

  30  ℓ

  7.93  gal

  Hydraulic tank

  200  ℓ

  52.88  gal

• Performance

  Travel Speed (Forward, Maximum)

  43  km/h

  26.72  mph

  Travel Speed (Reverse, Maximum)

  43  km/h

  26.72  mph

• Dimensions

  Overall Length

  10,810  mm

  35'6"  ft.in

  Overall Width

  4,620  mm

  15'2"  ft.in

  Overall Height

  3,700  mm

  12'2"  ft.in

  Ground clearance

  645  mm

  2'1"  ft.in

  Moldboard

  4,620  mm

  15'2"  ft.in

  Length of Between Counterweight to Ripper

  12,500  mm

  41'0"  ft.in

  Height to Top of ROPS Frame

  3,700  mm

  12'2"  ft.in
