Wheel Loaders
HL730-9
-
Operating Weight
9.8 ton
-
Bucket Capacity
1.9 m³
-
Emission
TIER 3
-
Rated Power
125 hp / 2,100 rpm
- Catalog
Specifications
-
General
Operating Weight
9.8 ton
Bucket Capacity
1.9 m³
-
Engine
Emission
TIER 3
Engine model
QSB4.5
Rated Power
125 hp / 2,100 rpm
Max. Torque
56 kgf·m / 1,400 rpm
-
Hydraulic System
Type
Load-sensing hydraulic system
-
Tank Capacity
Fuel tank
200 ℓ
Engine Oil
11 ℓ
Hydraulic tank
121 ℓ
-
Dimensions
Overall Length
6,950 mm
Overall Width
2,450 mm
Overall Height
3,170 mm
Ground clearance
370 mm
Wheelbase
2,750 mm
-
Tire
Tires (STD)
17.5-25, L3
-
Performance
Tipping Load (Staight)
7,900 kg
Tipping Load (Full-Turn)
6,900 kg
Cycle time (Raise from Carry Position)
5.4 sec
Cycle time (Lower, empty, foat down)
2.8 sec
Cycle time (Dump, at maximum raise)
1.0 sec
Travel speed (forward, Maximum)
37.2 km/h
Travel speed (Reverse, Maximum)
23.4 km/h
-
Operating Range
Hinge Pin Height at Maximum Lift
3,640 mm
Dump Clearance at Maximum lift and 45˚ Discharge
2,700 mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
