Specifications

• General

  Operating Weight

  26.450  ton

  58312.28  lb

  Bucket Capacity

  4.8  m³

  6.28  yd³

• Engine

  Emission

  TIER 3

  Engine model

  CUMMINS / X12

  CUMMINS / X12

  Rated Power

  335  hp / 2,100 rpm

  249.58  kw / 2,100 rpm

  Max. Torque

  170.7  kgf·m / 1,400 rpm

  1234.28  lbf.ft / 1,400 rpm

• Hydraulic System

  Type

  Load sensing hydraulic system

  Load sensing hydraulic system

• Tank Capacity

  Fuel tank

  400  ℓ

  105.75  gal

  Engine Oil

  34  ℓ

  8.99  gal

  Hydraulic tank

  166  ℓ

  43.89  gal

• Dimensions

  Overall Length

  7,780  mm

  25'6"  ft.in

  Overall Width

  3,250  mm

  10'8"  ft.in

  Overall Height

  3,590  mm

  11'9"  ft.in

  Ground clearance

  460  mm

  1'6"  ft.in

  Wheelbase

  3,550  mm

  11'8"  ft.in

• Tire

  Type

  Tubeless, loader design tires

  Tubeless, loader design tires

  Tires (STD)

  26.5R25 L3 ★★

  26.5R25 L3 ★★

  Option Include

  26.5R25 L5 ★★ / 26.5R25, XHA2 ★★ / 26.5-25 L3 32PR

  26.5R25 L5 ★★ / 26.5R25, XHA2 ★★ / 26.5-25 L3 32PR

• Performance

  Tipping Load (Staight)

  19,750  kg

  43541.3  lb

  Tipping Load (Full-Turn)

  16,950  kg

  37368.36  lb

  Cycle time (Raise from Carry Position)

  6.2  sec

  6.2  sec

  Cycle time (Lower, empty, foat down)

  4.2  sec

  4.2  sec

  Cycle time (Dump, at maximum raise)

  1.5  sec

  1.5  sec

  Travel speed (forward, Maximum)

  37.1  km/h

  23.05  mph

  Travel speed (Reverse, Maximum)

  24.9  km/h

  15.47  mph

• Operating Range

  Hinge Pin Height at Maximum Lift

  4,425  mm

  14'6"  ft.in

  Dump Clearance at Maximum lift and 45˚ Discharge

  3,120  mm

  10'3"  ft.in
