Specifications

• General

  Operating Weight

  18.3  ton

  40344.6  lb

  Bucket Capacity

  3.3  m³

  4.32  yd³

• Engine

  Emission

  TIER 2

  Engine model

  WEICHAI

  WEICHAI

  Rated Power

  220  hp / 2,200 rpm

  163.9  kw / 2,200 rpm

  Max. Torque

  87.7  kgf·m / - rpm

  634.13  lbf.ft / - rpm

• Hydraulic System

  Type

  Parallel shaft power shift automatic transmission

  Parallel shaft power shift automatic transmission

• Tank Capacity

  Fuel tank

  280  ℓ

  74.03  gal

  Engine Oil

  22  ℓ

  5.82  gal

  Hydraulic tank

  200  ℓ

  52.88  gal

• Dimensions

  Overall Length

  8,200  mm

  26'11"  ft.in

  Overall Width

  3,100  mm

  10'2"  ft.in

  Overall Height

  5,175  mm

  16'12"  ft.in

  Ground clearance

  400  mm

  1'4"  ft.in

  Wheelbase

  3,300  mm

  10'10"  ft.in

• Tire

  Type

  -

  Tires (STD)

  23.5-25-18 L3

  23.5-25-18 L3

  Option Include

  -

• Performance

  Breakout force

  -

  Tipping Load (Staight)

  12,300  kg

  27116.86  lb

  Tipping Load (Full-Turn)

  11,100  kg

  24471.32  lb

  Cycle time (Raise from Carry Position)

  5.1  sec

  5.1  sec

  Cycle time (Lower, empty, foat down)

  3.8  sec

  3.8  sec

  Cycle time (Dump, at maximum raise)

  1.1  sec

  1.1  sec

  Travel speed (forward, Maximum)

  37  km/h

  22.99  mph

  Travel speed (Reverse, Maximum)

  12  km/h

  7.46  mph

• Operating Range

  Hinge Pin Height at Maximum Lift

  -

  Dump Clearance at Maximum lift and 45˚ Discharge

  3,100  mm

  10'2"  ft.in
