Specifications

• General

  Operating Weight

  26.5  ton

  58422.51  lb

  Bucket Capacity

  4.8  m³

  6.28  yd³

• Engine

  Emission

  TIER 4 FINAL

  Engine model

  Cummins / X12

  Cummins / X12

  Rated Power

  335  hp / 2,100 rpm

  249.58  kw / 2,100 rpm

  Max. Torque

  178  kgf·m / 1,400 rpm

  1287.06  lbf.ft / 1,400 rpm

• Hydraulic System

  Type

  Load sensing hydraulic system

  Load sensing hydraulic system

• Tank Capacity

  Fuel tank

  400  ℓ

  105.75  gal

  Engine Oil

  34  ℓ

  8.99  gal

  Hydraulic tank

  151  ℓ

  39.92  gal

• Dimensions

  Overall Length

  7,780  mm

  25'6"  ft.in

  Overall Width

  2,975  mm

  9'9"  ft.in

  Overall Height

  3,720  mm

  12'2"  ft.in

  Ground clearance

  460  mm

  1'6"  ft.in

  Wheelbase

  3,550  mm

  11'8"  ft.in

• Tire

  Type

  Tubeless, loader design tires

  Tubeless, loader design tires

  Tires (STD)

  26.5R25, ★★, L3

  26.5R25, ★★, L3

  Option Include

  26.5R25, ★★, XHA2 26.5-25, 28PR, L3 26.5-25, 32PR, L3

  26.5R25, ★★, XHA2 26.5-25, 28PR, L3 26.5-25, 32PR, L3

• Performance

  Tipping Load (Staight)

  20,000  kg

  44092.46  lb

  Tipping Load (Full-Turn)

  17,300  kg

  38139.98  lb

  Cycle time (Raise from Carry Position)

  5.9  sec

  5.9  sec

  Cycle time (Lower, empty, foat down)

  3.9  sec

  3.9  sec

  Cycle time (Dump, at maximum raise)

  1.7  sec

  1.7  sec

  Travel speed (forward, Maximum)

  36.5  km/h

  22.68  mph

  Travel speed (Reverse, Maximum)

  24.6  km/h

  15.29  mph

• Operating Range

  Hinge Pin Height at Maximum Lift

  4,425  mm

  14'6"  ft.in

  Dump Clearance at Maximum lift and 45˚ Discharge

  3,120  mm

  10'3"  ft.in
