Specifications

• General

  Operating Weight

  34.4  ton

  75839.03  lb

  Bucket Capacity

  6.5  m³

  8.5  yd³

• Engine

  Emission

  STAGE V

  Engine model

  -

  Rated Power

  355  hp / 2,000 rpm

  264.48  kw / 2,000 rpm

  Max. Torque

  190  kgf·m / 1,400 rpm

  1373.83  lbf.ft / 1,400 rpm

• Hydraulic System

  Type

  Load sensing hydraulic system

  Load sensing hydraulic system

• Tank Capacity

  Fuel tank

  440  ℓ

  116.33  gal

  Engine Oil

  34  ℓ

  8.99  gal

  Hydraulic tank

  200  ℓ

  52.88  gal

• Dimensions

  Overall Length

  10,300  mm

  33'10"  ft.in

  Overall Width

  3,420  mm

  11'3"  ft.in

  Overall Height

  3,995  mm

  13'1"  ft.in

  Ground clearance

  476  mm

  1'7"  ft.in

  Wheelbase

  3,800  mm

  12'6"  ft.in

• Tire

  Type

  Tubeless, loader design tires

  Tubeless, loader design tires

  Tires (STD)

  29.5R25 L3 XHA2 (Michelin)

  29.5R25 L3 XHA2 (Michelin)

  Option Include

  29.5R25 L3 ★★ (Triangle)

  29.5R25 L3 ★★ (Triangle)

• Performance

  Tipping Load (Staight)

  28,400  kg

  62611.29  lb

  Tipping Load (Full-Turn)

  24,800  kg

  54674.65  lb

  Cycle time (Raise from Carry Position)

  6.1  sec

  6.1  sec

  Cycle time (Lower, empty, foat down)

  4.3  sec

  4.3  sec

  Cycle time (Dump, at maximum raise)

  1.7  sec

  1.7  sec

  Travel speed (forward, Maximum)

  34  km/h

  21.13  mph

  Travel speed (Reverse, Maximum)

  25.6  km/h

  15.91  mph

• Operating Range

  Hinge Pin Height at Maximum Lift

  4,750  mm

  15'7"  ft.in

  Dump Clearance at Maximum lift and 45˚ Discharge

  3,360  mm

  11'0"  ft.in
