Wheel Loaders
HL975A CVT
-
Operating Weight
26.5 ton
-
Bucket Capacity
5.2 m³
-
Emission
STAGE V
-
Rated Power
335 hp / 2,100 rpm
- Catalog
Specifications
-
General
Operating Weight
26.5 ton
Bucket Capacity
5.2 m³
-
Engine
Emission
STAGE V
Engine model
CUMMINS / X12
Rated Power
335 hp / 2,100 rpm
-
Hydraulic System
Type
Load sensing hydraulic system
-
Tank Capacity
Fuel tank
400 ℓ
Engine Oil
34 ℓ
Hydraulic tank
166 ℓ
-
Dimensions
Overall Length
7,780 mm
Overall Width
3,590 mm
Overall Height
2,975 mm
Ground clearance
460 mm
Wheelbase
3,550 mm
-
Tire
Type
Tubeless, loader design tires
Tires (STD)
26.5R25, ★★, L3
Option Include
26.5-25, 32PR, L3 / 26.5R25, ★, XHA
-
Performance
Tipping Load (Staight)
19,800 kg
Tipping Load (Full-Turn)
17,200 kg
Cycle time (Raise from Carry Position)
6.5 sec
Cycle time (Lower, empty, foat down)
4.4 sec
Cycle time (Dump, at maximum raise)
1.9 sec
Travel speed (forward, Maximum)
36 km/h
Travel speed (Reverse, Maximum)
36 km/h
-
Operating Range
Hinge Pin Height at Maximum Lift
4,425 mm
Dump Clearance at Maximum lift and 45˚ Discharge
3,120 mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
