Wheel Loaders
HL985A
-
Operating Weight
33.8 ton
-
Bucket Capacity
7.0 m³
-
Emission
STAGE V
-
Rated Power
430 hp / 1,000 rpm
- Catalog
3D View
This 3D image is for illustrative purposes only and may not represent the actual product.
Specifications
-
General
Operating Weight
33.8 ton
Bucket Capacity
7.0 m³
-
Engine
Emission
STAGE V
Engine model
CUMMINS X12
Rated Power
430 hp / 1,000 rpm
Max. Torque
234.53 kgf·m / 1,000 rpm
-
Hydraulic System
Type
Load sensing hydraulic system
-
Tank Capacity
Fuel tank
440 ℓ
Engine Oil
34 ℓ
Hydraulic tank
200 ℓ
-
Dimensions
Overall Length
10,000 mm
Overall Width
3,600 mm
Overall Height
6,740 mm
Ground clearance
487 mm
Wheelbase
3,800 mm
-
Tire
Type
Tubeless, loader design tires
Tires (STD)
875/65R29 L3 ★★
Option Include
29.5R25 L3 ★★
-
Performance
Tipping Load (Staight)
26,500 kg
Tipping Load (Full-Turn)
22,950 kg
Cycle time (Raise from Carry Position)
6.1 sec
Cycle time (Lower, empty, foat down)
4.3 sec
Cycle time (Dump, at maximum raise)
1.7 sec
Travel speed (forward, Maximum)
40 km/h
Travel speed (Reverse, Maximum)
27.1 km/h
-
Operating Range
Hinge Pin Height at Maximum Lift
4,750 mm
Dump Clearance at Maximum lift and 45˚ Discharge
3,360 mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
