Specifications

• General

  Operating Weight

  19.5  ton

  42990.15  lb

  Bucket Capacity

  3.5  m³

  4.58  yd³

• Engine

  Emission

  TIER 2

  Engine model

  WEICHAI

  WEICHAI

  Rated Power

  240  hp / 2,200 rpm

  178.8  kw / 2,200 rpm

  Max. Torque

  94.83  kgf·m / - rpm

  685.69  lbf.ft / - rpm

• Hydraulic System

  Type

  Parallel shaft power shift automatic transmission

  Parallel shaft power shift automatic transmission

• Tank Capacity

  Fuel tank

  280  ℓ

  74.03  gal

  Engine Oil

  22  ℓ

  5.82  gal

  Hydraulic tank

  200  ℓ

  52.88  gal

• Dimensions

  Overall Length

  8,280  mm

  27'2"  ft.in

  Overall Width

  3,005  mm

  9'10"  ft.in

  Overall Height

  5,420  mm

  17'9"  ft.in

  Ground clearance

  402  mm

  1'4"  ft.in

  Wheelbase

  3,300  mm

  10'10"  ft.in

• Tire

  Type

  -

  Tires (STD)

  23.5-25-20 L3

  23.5-25-20 L3

  Option Include

  -

• Performance

  Breakout force

  -

  Tipping Load (Staight)

  13,780  kg

  30379.7  lb

  Tipping Load (Full-Turn)

  12,100  kg

  26675.94  lb

  Cycle time (Raise from Carry Position)

  5  sec

  5  sec

  Cycle time (Lower, empty, foat down)

  3.4  sec

  3.4  sec

  Cycle time (Dump, at maximum raise)

  1.1  sec

  1.1  sec

  Travel speed (forward, Maximum)

  37  km/h

  22.99  mph

  Travel speed (Reverse, Maximum)

  12  km/h

  7.46  mph

• Operating Range

  Hinge Pin Height at Maximum Lift

  -

  Dump Clearance at Maximum lift and 45˚ Discharge

  3,200  mm

  10'6"  ft.in
