Specifications

• General

  Operating Weight

  15.8  ton

  34833.04  lb

  Bucket Capacity

  2.8  m³

  3.66  yd³

• Engine

  Emission

  STAGE V

  Engine model

  CUMMINS / B6.7

  CUMMINS / B6.7

  Rated Power

  200  hp / 2,200 rpm

  149  kw / 2,200 rpm

  Max. Torque

  101  kgf·m / 1,300 rpm

  730.3  lbf.ft / 1,300 rpm

• Hydraulic System

  Type

  Load sensing hydraulic system

  Load sensing hydraulic system

• Tank Capacity

  Fuel tank

  230  ℓ

  60.81  gal

  Engine Oil

  18  ℓ

  4.76  gal

  Hydraulic tank

  110  ℓ

  29.08  gal

• Dimensions

  Overall Length

  6,430  mm

  21'1"  ft.in

  Overall Width

  2,530  mm

  8'4"  ft.in

  Overall Height

  3,520  mm

  11'7"  ft.in

  Ground clearance

  410  mm

  1'4"  ft.in

  Wheelbase

  3,050  mm

  10'0"  ft.in

• Tire

  Type

  Tubeless, loader design tires

  Tubeless, loader design tires

  Tires (STD)

  20.5 R25,★★ ,L3

  20.5 R25,★★ ,L3

  Option Include

  20.5 R25, ★, XHA 20.5-25, 16PR, L3 20.5-25, 16PR, L5

  20.5 R25, ★, XHA 20.5-25, 16PR, L3 20.5-25, 16PR, L5

• Performance

  Tipping Load (Staight)

  11,350  kg

  25022.47  lb

  Tipping Load (Full-Turn)

  9,850  kg

  21715.54  lb

  Cycle time (Raise from Carry Position)

  5.5  sec

  5.5  sec

  Cycle time (Lower, empty, foat down)

  3.9  sec

  3.9  sec

  Cycle time (Dump, at maximum raise)

  1.8  sec

  1.8  sec

  Travel speed (forward, Maximum)

  39.2  km/h

  24.36  mph

  Travel speed (Reverse, Maximum)

  24.9  km/h

  15.47  mph

• Operating Range

  Hinge Pin Height at Maximum Lift

  3,940  mm

  12'11"  ft.in

  Dump Clearance at Maximum lift and 45˚ Discharge

  2,785  mm

  9'2"  ft.in
