Specifications

• General

  Operating Weight

  13.6  ton

  29982.87  lb

  Bucket Capacity

  2.3  m³

  3.01  yd³

• Engine

  Emission

  STAGE V

  Engine model

  CUMMINS / B6.7

  CUMMINS / B6.7

  Rated Power

  155  hp / 2,200 rpm

  115.48  kw / 2,200 rpm

  Max. Torque

  76  kgf·m / 1,300 rpm

  549.53  lbf.ft / 1,300 rpm

• Hydraulic System

  Type

  Load sensing hydraulic system

  Load sensing hydraulic system

• Tank Capacity

  Fuel tank

  2,200  ℓ

  581.63  gal

  Engine Oil

  18  ℓ

  4.76  gal

  Hydraulic tank

  90  ℓ

  23.79  gal

• Dimensions

  Overall Length

  6,430  mm

  21'1"  ft.in

  Overall Width

  2,450  mm

  8'0"  ft.in

  Overall Height

  3,430  mm

  11'3"  ft.in

  Ground clearance

  417  mm

  1'4"  ft.in

  Wheelbase

  3,000  mm

  9'10"  ft.in

• Tire

  Type

  Tubeless, loader design tires

  Tubeless, loader design tires

  Tires (STD)

  20.5 R25, ★★, L3

  20.5 R25, ★★, L3

  Option Include

  20.5-25 16PR L3 20.5-25 16PR L5 20.5 R25, ★, XHA

  20.5-25 16PR L3 20.5-25 16PR L5 20.5 R25, ★, XHA

• Performance

  Tipping Load (Staight)

  10,470  kg

  23082.4  lb

  Tipping Load (Full-Turn)

  9,005  kg

  19852.63  lb

  Cycle time (Raise from Carry Position)

  5.5  sec

  5.5  sec

  Cycle time (Lower, empty, foat down)

  3.9  sec

  3.9  sec

  Cycle time (Dump, at maximum raise)

  1.9  sec

  1.9  sec

  Travel speed (forward, Maximum)

  40  km/h

  24.85  mph

  Travel speed (Reverse, Maximum)

  26.4  km/h

  16.4  mph

• Operating Range

  Hinge Pin Height at Maximum Lift

  3,820  mm

  12'6"  ft.in

  Dump Clearance at Maximum lift and 45˚ Discharge

  2,765  mm

  9'1"  ft.in
