Specifications

• General

  Operating Weight

  24.7  ton

  54454.19  lb

  Bucket Capacity

  5.2  m³

  6.8  yd³

• Engine

  Emission

  STAGE V

  Engine model

  CUMMINS / L9

  CUMMINS / L9

  Rated Power

  325  hp / 2,100 rpm

  242.13  kw / 2,100 rpm

  Max. Torque

  167  kgf·m / 1,100 rpm

  1207.53  lbf.ft / 1,100 rpm

• Hydraulic System

  Type

  Load sensing hydraulic system

  Load sensing hydraulic system

• Tank Capacity

  Fuel tank

  365  ℓ

  96.5  gal

  Engine Oil

  22.7  ℓ

  6  gal

  Hydraulic tank

  152  ℓ

  40.19  gal

• Dimensions

  Overall Length

  7,395  mm

  24'3"  ft.in

  Overall Width

  2,980  mm

  9'9"  ft.in

  Overall Height

  3,720  mm

  12'2"  ft.in

  Ground clearance

  480  mm

  1'7"  ft.in

  Wheelbase

  3,500  mm

  11'6"  ft.in

• Tire

  Type

  Tubeless, loader design tires

  Tubeless, loader design tires

  Tires (STD)

  26.5R25 L3, ★★, L3

  26.5R25 L3, ★★, L3

  Option Include

  26.5-25, 20PR L5 26.5R25 XHA, ★, XHA 26.5-25 20PR L3

  26.5-25, 20PR L5 26.5R25 XHA, ★, XHA 26.5-25 20PR L3

• Performance

  Tipping Load (Staight)

  19,550  kg

  43100.38  lb

  Tipping Load (Full-Turn)

  16,890  kg

  37236.08  lb

  Cycle time (Raise from Carry Position)

  6  sec

  6  sec

  Cycle time (Lower, empty, foat down)

  4.3  sec

  4.3  sec

  Cycle time (Dump, at maximum raise)

  1.5  sec

  1.5  sec

  Travel speed (forward, Maximum)

  40  km/h

  24.85  mph

  Travel speed (Reverse, Maximum)

  27.8  km/h

  17.27  mph

• Operating Range

  Hinge Pin Height at Maximum Lift

  4,325  mm

  14'2"  ft.in

  Dump Clearance at Maximum lift and 45˚ Discharge

  3,080  mm

  10'1"  ft.in
