Specifications

• General

  Operating Weight

  16.5  ton

  36376.28  lb

  Bucket Capacity

  2.7  m³

  3.53  yd³

• Engine

  Emission

  STAGE V

  Engine model

  CUMMINS / B6.7

  CUMMINS / B6.7

  Rated Power

  200  hp / 2,200 rpm

  149  kw / 2,200 rpm

  Max. Torque

  101  kgf·m / 1,300 rpm

  730.3  lbf.ft / 1,300 rpm

• Hydraulic System

  Type

  Load sensing hydraulic system

  Load sensing hydraulic system

• Tank Capacity

  Fuel tank

  230  ℓ

  60.81  gal

  Engine Oil

  18  ℓ

  4.76  gal

  Hydraulic tank

  110  ℓ

  29.08  gal

• Dimensions

  Overall Length

  6,530  mm

  21'5"  ft.in

  Overall Width

  2,530  mm

  8'4"  ft.in

  Overall Height

  3,520  mm

  11'7"  ft.in

  Ground clearance

  410  mm

  1'4"  ft.in

  Wheelbase

  3,050  mm

  10'0"  ft.in

• Tire

  Type

  Tubeless, loader design tires

  Tubeless, loader design tires

  Tires (STD)

  20.5R25 L3 ★★

  20.5R25 L3 ★★

  Option Include

  20.5R25 XHA ★ 20.5-25 L3 16PR 20.5-25 L5 16PR

  20.5R25 XHA ★ 20.5-25 L3 16PR 20.5-25 L5 16PR

• Performance

  Tipping Load (Staight)

  11,000  kg

  24250.85  lb

  Tipping Load (Full-Turn)

  9,550  kg

  21054.15  lb

  Cycle time (Raise from Carry Position)

  5.5  sec

  5.5  sec

  Cycle time (Lower, empty, foat down)

  3.9  sec

  3.9  sec

  Cycle time (Dump, at maximum raise)

  2.5  sec

  2.5  sec

  Travel speed (forward, Maximum)

  39.2  km/h

  24.36  mph

  Travel speed (Reverse, Maximum)

  24.9  km/h

  15.47  mph

• Operating Range

  Hinge Pin Height at Maximum Lift

  4,020  mm

  13'2"  ft.in

  Dump Clearance at Maximum lift and 45˚ Discharge

  2,850  mm

  9'4"  ft.in
