Wheel Loaders
HL960 T3
-
Operating Weight
18.9 ton
-
Bucket Capacity
3.3 m³
-
Emission
TIER 3
-
Rated Power
215 hp / 2,100 rpm
- Catalog
Specifications
-
General
Operating Weight
18.9 ton
Bucket Capacity
3.3 m³
-
Engine
Emission
TIER 3
Engine model
HYUNDAI / HE6.7
Rated Power
215 hp / 2,100 rpm
Max. Torque
96.77 kgf·m / 1,400 rpm
-
Hydraulic System
Type
Load sensing hydraulic system
-
Tank Capacity
Fuel tank
260 ℓ
Engine Oil
18 ℓ
Hydraulic tank
110 ℓ
-
Dimensions
Overall Length
6,870 mm
Overall Width
2,770 mm
Overall Height
3,580 mm
Ground clearance
410 mm
Wheelbase
3,300 mm
-
Tire
Type
Tubeless, loader design tires
Tires (STD)
23.5R25 L3 ★★
Option Include
23.5-25 L5 20PR / 23.5R25 L3 XHA2 ★ / 23.5-25 L3 20PR
-
Performance
Tipping Load (Staight)
14,000 kg
Cycle time (Raise from Carry Position)
5.8 sec
Cycle time (Lower, empty, foat down)
3.7 sec
Cycle time (Dump, at maximum raise)
2.0 sec
Travel speed (forward, Maximum)
37.9 km/h
Travel speed (Reverse, Maximum)
24.8 km/h
-
Operating Range
Dump Clearance at Maximum lift and 45˚ Discharge
2,935 mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
