Specifications

• General

  Type

  Medium Excavators

  Operating Weight

  14.2  ton

  31305.65  lb

  Bucket Capacity

  0.72  m³

  0.94  yd³

• Engine

  Emission

  ~TIER 2

  Engine model

  HYUNDAI HM4.2

  HYUNDAI HM4.2

  Rated Power

  105  hp / 2,200 rpm

  78.22  kw / 2,200 rpm

  Max. Torque

  37.5  kgf·m / 1,500 rpm

  271.15  lbf.ft / 1,500 rpm

• Hydraulic System

  Main Pumps Rated Flow

  2x130  ℓ/min

  2x130  ℓ/min

  Implement Circuit

  350  kgf/cm²

  4978.19  psi

• Tank Capacity

  Fuel Tank

  270  ℓ

  71.38  gal

  Hydraulic Tank

  124  ℓ

  32.78  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  12  rpm

  12  rpm

  Travel Speed

  5.5  km/h

  3.42  mph

  Max. Traction Force

  13,300  kgf

  6032.78  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  10,400  kgf

  4717.36  lbf

  Arm Digging Force (ISO)

  7,900  kgf

  3583.38  lbf

• Dimensions

  Overall Length

  7,870  mm

  25'10"  ft.in

  Overall Width

  2,600  mm

  8'6"  ft.in

  Overall Height

  2,860  mm

  9'5"  ft.in

  Tail Swing Radius

  2,350  mm

  7'9"  ft.in

  Tumbler Distance

  3,000  mm

  9'10"  ft.in

  Ground Clearance

  940  mm

  3'1"  ft.in

• Operating Range

  Boom Length

  4,600  mm

  15'1"  ft.in

  Arm Length

  2,100  mm

  6'11"  ft.in

  Max. Digging Reach

  7,920  mm

  25'12"  ft.in

  Max. Digging Depth

  5,150  mm

  16'11"  ft.in

  Max. Digging Height

  8,100  mm

  26'7"  ft.in

  Max. Dumping Height

  5,750  mm

  18'10"  ft.in

  Min. Swing Radius

  2,670  mm

  8'9"  ft.in
