Specifications

• General

  Type

  Wheel Excavators

  Operating Weight

  6.355  ton

  14010.38  lb

  Bucket Capacity

  0.18  m³

  0.24  yd³

• Engine

  Emission

  STAGE V

  Engine model

  HYUNDAI DM02VB (D24)

  HYUNDAI DM02VB (D24)

  Rated Power

  65.9  hp / 2,400 rpm

  49.1  kw / 2,400 rpm

  Max. Torque

  25.29  kgf·m / - rpm

  182.86  lbf.ft / - rpm

• Hydraulic System

  Main Pumps Rated Flow

  2*60  ℓ/min

  2*60  ℓ/min

  Implement Circuit

  220  kgf/cm²

  3129.15  psi

• Tank Capacity

  Fuel Tank

  125  ℓ

  33.05  gal

  Hydraulic Tank

  70  ℓ

  18.51  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  8.4  rpm

  8.4  rpm

  Travel Speed

  32  km/h

  19.88  mph

  Max. Traction Force

  3,042  kgf

  1379.83  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  3,567  kgf

  1617.96  lbf

  Arm Digging Force (ISO)

  2,639  kgf

  1197.03  lbf

• Dimensions

  Overall Length

  6,200  mm

  20'4"  ft.in

  Overall Width

  2,100  mm

  6'11"  ft.in

  Overall Height

  2,800  mm

  9'2"  ft.in

  Tail Swing Radius

  1,680  mm

  5'6"  ft.in

  Tumbler Distance

  2,100  mm

  6'11"  ft.in

  Ground Clearance

  315  mm

  1'0"  ft.in

• Operating Range

  Boom Length

  3,000  mm

  9'10"  ft.in

  Arm Length

  1,600  mm

  5'3"  ft.in

  Max. Digging Reach

  6,150  mm

  20'2"  ft.in

  Max. Digging Depth

  3,490  mm

  11'5"  ft.in

  Max. Digging Height

  6,045  mm

  19'10"  ft.in

  Max. Dumping Height

  4,290  mm

  14'1"  ft.in

  Min. Swing Radius

  2,380  mm

  7'10"  ft.in
