Specifications

• General

  Type

  Large Excavators

  Operating Weight

  100.2  ton

  220903.22  lb

  Bucket Capacity

  6.8  m³

  8.89  yd³

• Engine

  Emission

  TIER 3

  Engine model

  Perkins 2806D

  Perkins 2806D

  Rated Power

  630  hp / 2,100 rpm

  469.35  kw / 2,100 rpm

  Max. Torque

  282  kgf·m / 1,400 rpm

  2039.06  lbf.ft / 1,400 rpm

• Hydraulic System

  Main Pumps Rated Flow

  523  ℓ/min

  523  ℓ/min

  Implement Circuit

  367  kgf/cm²

  5219.99  psi

• Tank Capacity

  Fuel Tank

  1,138  ℓ

  300.86  gal

  Hydraulic Tank

  533  ℓ

  140.91  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  6.3  rpm

  6.3  rpm

  Travel Speed

  4.3  km/h

  2.67  mph

  Max. Traction Force

  78,700  kgf

  35697.71  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  40,000  kgf

  18143.69  lbf

  Arm Digging Force (ISO)

  36,220  kgf

  16429.11  lbf

• Dimensions

  Overall Length

  14,550  mm

  47'9"  ft.in

  Overall Width

  3,982  mm

  13'1"  ft.in

  Overall Height

  5,550  mm

  18'3"  ft.in

  Tail Swing Radius

  4,620  mm

  15'2"  ft.in

  Tumbler Distance

  5,100  mm

  16'9"  ft.in

  Ground Clearance

  860  mm

  2'10"  ft.in

• Operating Range

  Boom Length

  8,400  mm

  27'7"  ft.in

  Arm Length

  3,750  mm

  12'4"  ft.in

  Max. Digging Reach

  14,275  mm

  46'10"  ft.in

  Max. Digging Depth

  8,795  mm

  28'10"  ft.in

  Max. Digging Height

  13,840  mm

  45'5"  ft.in

  Max. Dumping Height

  9,440  mm

  30'12"  ft.in

  Min. Swing Radius

  6,295  mm

  20'8"  ft.in
