Specifications

• General

  Type

  Compact Excavators

  Operating Weight

  6.08  ton

  13404.11  lb

  Bucket Capacity

  0.18  m³

  0.24  yd³

• Engine

  Emission

  STAGE V

  Engine model

  HYUNDAI DM02V

  HYUNDAI DM02V

  Rated Power

  65.9  hp / 2,400 rpm

  49.1  kw / 2,400 rpm

  Max. Torque

  25.3  kgf·m / 1,600 rpm

  182.94  lbf.ft / 1,600 rpm

• Hydraulic System

  Main Pumps Rated Flow

  40.3+10  ℓ/min

  40.3+10  ℓ/min

  Implement Circuit

  -

• Tank Capacity

  Fuel Tank

  125  ℓ

  33.05  gal

  Hydraulic Tank

  70  ℓ

  18.51  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  9.4  rpm

  9.4  rpm

  Travel Speed

  4.5  km/h

  2.8  mph

  Max. Traction Force

  5,221  kgf

  2368.21  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  4,292  kgf

  1946.82  lbf

  Arm Digging Force (ISO)

  2,886  kgf

  1309.07  lbf

• Dimensions

  Overall Length

  5,970  mm

  19'7"  ft.in

  Overall Width

  1,880  mm

  6'2"  ft.in

  Overall Height

  2,075  mm

  6'10"  ft.in

  Tail Swing Radius

  1,650  mm

  5'5"  ft.in

  Tumbler Distance

  2,010  mm

  6'7"  ft.in

  Ground Clearance

  687  mm

  2'3"  ft.in

• Operating Range

  Boom Length

  3,000  mm

  9'10"  ft.in

  Arm Length

  1,800  mm

  5'11"  ft.in

  Max. Digging Reach

  6,150  mm

  20'2"  ft.in

  Max. Digging Depth

  3,770  mm

  12'4"  ft.in

  Max. Digging Height

  5,760  mm

  18'11"  ft.in

  Max. Dumping Height

  4,000  mm

  13'1"  ft.in

  Min. Swing Radius

  2,375  mm

  7'10"  ft.in
