Excavators
Type
Medium Excavators
Operating Weight
20.83  ton
Emission
N/A
Rated Power
148  hp / 2,000 rpm
General
Type
Medium Excavators
Operating Weight
20.83  ton
Bucket Capacity
0.92  m³
Engine
Emission
N/A
Engine model
HYUNDAI HM5.9
Rated Power
148  hp / 2,000 rpm
Max. Torque
64  kgf·m / 1,300 rpm
Hydraulic System
Main Pumps Rated Flow
2x222  ℓ/min
Implement Circuit
350  kgf/cm²
Tank Capacity
Fuel Tank
340  ℓ
Hydraulic Tank
160  ℓ
Performance
Swing Speed
12.2  rpm
Travel Speed
5.7  km/h
Max. Traction Force
21,100  kgf
Max. Gradeability
35  deg
Bucket Digging Force (ISO)
15,500  kgf
Arm Digging Force (ISO)
10,900  kgf
Dimensions
Overall Length
9,530  mm
Overall Width
2,800  mm
Overall Height
3,030  mm
Tail Swing Radius
2,845  mm
Tumbler Distance
3,360  mm
Ground Clearance
470  mm
Operating Range
Boom Length
5,680  mm
Arm Length
2,920  mm
Max. Digging Reach
9,980  mm
Max. Digging Depth
6,730  mm
Max. Digging Height
9,600  mm
Max. Dumping Height
6,780  mm
Min. Swing Radius
3,740  mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
