Excavators
Type
Compact Excavators
Operating Weight
8.35  ton
Emission
N/A
Rated Power
59.6  hp / 2,100 rpm
General
Type
Compact Excavators
Operating Weight
8.35  ton
Bucket Capacity
0.28  m³
Engine
Emission
N/A
Engine model
YANMAR 4TNV98
Rated Power
59.6  hp / 2,100 rpm
Max. Torque
24.5  kgf·m / 1,350 rpm
Hydraulic System
Main Pumps Rated Flow
2x72  ℓ/min
Implement Circuit
280  kgf/cm²
Tank Capacity
Fuel Tank
120  ℓ
Hydraulic Tank
71  ℓ
Performance
Swing Speed
9.6  rpm
Travel Speed
4.3  km/h
Max. Traction Force
7,400  kgf
Max. Gradeability
35  deg
Bucket Digging Force (ISO)
5,700  kgf
Arm Digging Force (ISO)
4,300  kgf
Dimensions
Overall Length
6,170  mm
Overall Width
2,300  mm
Overall Height
2,640  mm
Tail Swing Radius
1,280  mm
Tumbler Distance
2,200  mm
Ground Clearance
360  mm
Operating Range
Boom Length
3,400  mm
Arm Length
1,670  mm
Max. Digging Reach
6,960  mm
Max. Digging Depth
4,150  mm
Max. Digging Height
6,740  mm
Max. Dumping Height
4,730  mm
Min. Swing Radius
2,500  mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
