Specifications

• General

  Type

  Wheel Excavators

  Operating Weight

  11.1  ton

  24471.32  lb

  Bucket Capacity

  0.28  m³

  0.37  yd³

• Engine

  Emission

  STAGE V

  Engine model

  Hyundai D34

  Hyundai D34

  Rated Power

  100  hp / 2,000 rpm

  74.5  kw / 2,000 rpm

  Max. Torque

  43.85  kgf·m / 1,400 rpm

  317.07  lbf.ft / 1,400 rpm

• Hydraulic System

  Main Pumps Rated Flow

  200  ℓ/min

  200  ℓ/min

  Implement Circuit

  -

• Tank Capacity

  Fuel Tank

  160  ℓ

  42.3  gal

  Hydraulic Tank

  140  ℓ

  37.01  gal

  DEF/ ADBLUE Tank

  20  ℓ

  5.29  gal

• Performance

  Swing Speed

  10.5  rpm

  10.5  rpm

  Travel Speed

  37.4  km/h

  23.24  mph

  Max. Traction Force

  4,200  kgf

  1905.09  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  5,976  kgf

  2710.67  lbf

  Arm Digging Force (ISO)

  3,722  kgf

  1688.27  lbf

• Dimensions

  Overall Length

  7,319  mm

  24'0"  ft.in

  Overall Width

  2,450  mm

  8'0"  ft.in

  Overall Height

  3,000  mm

  9'10"  ft.in

  Tail Swing Radius

  1,600  mm

  5'3"  ft.in

  Tumbler Distance

  1,987  mm

  6'6"  ft.in

  Ground Clearance

  317  mm

  1'0"  ft.in

• Operating Range

  Boom Length

  1,890  mm

  6'2"  ft.in

  Arm Length

  2,250  mm

  7'5"  ft.in

  Max. Digging Reach

  7,820  mm

  25'8"  ft.in

  Max. Digging Depth

  4,245  mm

  13'11"  ft.in

  Max. Digging Height

  8,265  mm

  27'1"  ft.in

  Max. Dumping Height

  6,250  mm

  20'6"  ft.in

  Min. Swing Radius

  3,105  mm

  10'2"  ft.in
