Specifications

• General

  Type

  Large Excavators

  Operating Weight

  82.1  ton

  180999.55  lb

  Bucket Capacity

  5.2  m³

  6.8  yd³

• Engine

  Emission

  STAGE V

  Engine model

  2506J

  2506J

  Rated Power

  539.1  hp / 2,100 rpm

  401.63  kw / 2,100 rpm

  Max. Torque

  251.67  kgf·m / 1,400 rpm

  1819.75  lbf.ft / 1,400 rpm

• Hydraulic System

  Main Pumps Rated Flow

  504  ℓ/min

  504  ℓ/min

  Implement Circuit

  357  kgf/cm²

  5077.75  psi

• Tank Capacity

  Fuel Tank

  880  ℓ

  232.65  gal

  Hydraulic Tank

  435  ℓ

  115  gal

  DEF/ ADBLUE Tank

  47  ℓ

  12.43  gal

• Performance

  Swing Speed

  7.4  rpm

  7.4  rpm

  Travel Speed

  4.9  km/h

  3.04  mph

  Max. Traction Force

  64,138  kgf

  29092.5  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  98,600  kgf

  44724.2  lbf

  Arm Digging Force (ISO)

  29,100  kgf

  13199.54  lbf

• Dimensions

  Overall Length

  13,165  mm

  43'2"  ft.in

  Overall Width

  3,810  mm

  12'6"  ft.in

  Overall Height

  4,865  mm

  15'12"  ft.in

  Tail Swing Radius

  4,100  mm

  13'5"  ft.in

  Tumbler Distance

  4,730  mm

  15'6"  ft.in

  Ground Clearance

  830  mm

  2'9"  ft.in

• Operating Range

  Boom Length

  7,700  mm

  25'3"  ft.in

  Arm Length

  3,550  mm

  11'8"  ft.in

  Max. Digging Reach

  13,215  mm

  43'4"  ft.in

  Max. Digging Depth

  8,370  mm

  27'6"  ft.in

  Max. Digging Height

  12,000  mm

  39'4"  ft.in

  Max. Dumping Height

  8,380  mm

  27'6"  ft.in

  Min. Swing Radius

  5,730  mm

  18'10"  ft.in
