Specifications

• General

  Type

  Large Excavators

  Operating Weight

  120.7  ton

  266,098  lb

  Bucket Capacity

  8.57  m³

  11.21  yd³

• Engine

  Emission

  TIER 2

  Engine model

  CUMMINS QSK23

  CUMMINS QSK23

  Rated Power

  771  hp / 1,800 rpm

  574.4  kw / 1,800 rpm

  Max. Torque

  354  kgf·m / 1,350 rpm

  2559.67  lbf.ft / 1,350 rpm

• Hydraulic System

  Main Pumps Rated Flow

  3x504  ℓ/min

  3x504  ℓ/min

  Implement Circuit

  320  kgf/cm²

  4551.49  psi

• Tank Capacity

  Fuel Tank

  1,475  ℓ

  389.95  gal

  Hydraulic Tank

  670  ℓ

  177.13  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  5.6  rpm

  5.6  rpm

  Travel Speed

  3.2  km/h

  1.99  mph

  Max. Traction Force

  70,200  kgf

  31842.18  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  59,300  kgf

  26898.02  lbf

  Arm Digging Force (ISO)

  43,800  kgf

  19867.34  lbf

• Dimensions

  Overall Length

  14,520  mm

  47'8"  ft.in

  Overall Width

  5,560  mm

  18'3"  ft.in

  Overall Height

  6,190  mm

  20'4"  ft.in

  Tail Swing Radius

  4,865  mm

  15'12"  ft.in

  Tumbler Distance

  5,010  mm

  16'5"  ft.in

  Ground Clearance

  1,825  mm

  5'12"  ft.in

• Operating Range

  Boom Length

  7,550  mm

  24'9"  ft.in

  Arm Length

  3,440  mm

  11'3"  ft.in

  Max. Digging Reach

  13,760  mm

  45'2"  ft.in

  Max. Digging Depth

  8,010  mm

  26'3"  ft.in

  Max. Digging Height

  12,420  mm

  40'9"  ft.in

  Max. Dumping Height

  7,790  mm

  25'7"  ft.in

  Min. Swing Radius

  6,550  mm

  21'6"  ft.in
