Specifications

• General

  Type

  Large Excavators

  Operating Weight

  50.2  ton

  110672.07  lb

  Bucket Capacity

  3.2  m³

  4.18  yd³

• Engine

  Emission

  STAGE V

  Engine model

  CUMMINS X12

  CUMMINS X12

  Rated Power

  298  hp / 2,100 rpm

  222.01  kw / 2,100 rpm

  Max. Torque

  193.54  kgf·m / 1,400 rpm

  1399.43  lbf.ft / 1,400 rpm

• Hydraulic System

  Main Pumps Rated Flow

  2x390  ℓ/min

  2x390  ℓ/min

  Implement Circuit

  330  kgf/cm²

  4693.72  psi

• Tank Capacity

  Fuel Tank

  600  ℓ

  158.63  gal

  Hydraulic Tank

  275  ℓ

  72.7  gal

  DEF/ ADBLUE Tank

  70  ℓ

  18.51  gal

• Performance

  Swing Speed

  9  rpm

  9  rpm

  Travel Speed

  5.3  km/h

  3.29  mph

  Max. Traction Force

  39,674  kgf

  17995.82  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  26,050  kgf

  11816.08  lbf

  Arm Digging Force (ISO)

  29,410  kgf

  13340.15  lbf

• Dimensions

  Overall Length

  5,482  mm

  17'12"  ft.in

  Overall Width

  2,890  mm

  9'6"  ft.in

  Overall Height

  3,960  mm

  12'12"  ft.in

  Tail Swing Radius

  3,800  mm

  12'6"  ft.in

  Tumbler Distance

  4,475  mm

  14'8"  ft.in

  Ground Clearance

  1,340  mm

  4'5"  ft.in

• Operating Range

  Boom Length

  7,060  mm

  23'2"  ft.in

  Arm Length

  3,380  mm

  11'1"  ft.in

  Max. Digging Reach

  11,780  mm

  38'8"  ft.in

  Max. Digging Depth

  7,650  mm

  25'1"  ft.in

  Max. Digging Height

  10,905  mm

  35'9"  ft.in

  Max. Dumping Height

  7,790  mm

  25'7"  ft.in

  Min. Swing Radius

  4,875  mm

  15'12"  ft.in
