Specifications

• General

  Type

  Large Excavators

  Operating Weight

  29.54  ton

  65124.56  lb

  Bucket Capacity

  1.27  m³

  1.66  yd³

• Engine

  Emission

  TIER 3

  Engine model

  HYUNDAI HE6.7

  HYUNDAI HE6.7

  Rated Power

  227  hp / 1,900 rpm

  169.12  kw / 1,900 rpm

  Max. Torque

  97.00  kgf·m / 1,400 rpm

  701.38  lbf.ft / 1,400 rpm

• Hydraulic System

  Main Pumps Rated Flow

  2*266  ℓ/min

  2*266  ℓ/min

  Implement Circuit

  330  kgf/cm²

  4693.72  psi

• Tank Capacity

  Fuel Tank

  480  ℓ

  126.9  gal

  Hydraulic Tank

  320  ℓ

  84.6  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  11.1  rpm

  11.1  rpm

  Travel Speed

  5.7  km/h

  3.54  mph

  Max. Traction Force

  25,800  kgf

  11702.68  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  19,600  kgf

  8890.41  lbf

  Arm Digging Force (ISO)

  13,100  kgf

  5942.06  lbf

• Dimensions

  Overall Length

  10,590  mm

  34'9"  ft.in

  Overall Width

  3,400  mm

  11'2"  ft.in

  Overall Height

  3,100  mm

  10'2"  ft.in

  Tail Swing Radius

  3,200  mm

  10'6"  ft.in

  Tumbler Distance

  4,030  mm

  13'3"  ft.in

  Ground Clearance

  500  mm

  1'8"  ft.in

• Operating Range

  Boom Length

  6,250  mm

  20'6"  ft.in

  Arm Length

  3,050  mm

  10'0"  ft.in

  Max. Digging Reach

  10,810  mm

  35'6"  ft.in

  Max. Digging Depth

  7,330  mm

  24'1"  ft.in

  Max. Digging Height

  10,200  mm

  33'6"  ft.in

  Max. Dumping Height

  7,150  mm

  23'5"  ft.in

  Min. Swing Radius

  4,270  mm

  14'0"  ft.in
