Specifications

• General

  Type

  Compact Excavators

  Operating Weight

  7.68  ton

  16931.5  lb

  Bucket Capacity

  0.28  m³

  0.37  yd³

• Engine

  Emission

  TIER 2

  Engine model

  YANMAR 4TNV98L

  YANMAR 4TNV98L

  Rated Power

  46.3  hp / 2,200 rpm

  34.49  kw / 2,200 rpm

  Max. Torque

  -

• Hydraulic System

  Main Pumps Rated Flow

  156  ℓ/min

  156  ℓ/min

  Implement Circuit

  -

• Tank Capacity

  Fuel Tank

  132  ℓ

  34.9  gal

  Hydraulic Tank

  90  ℓ

  23.79  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  10.5  rpm

  10.5  rpm

  Travel Speed

  4.8  km/h

  2.98  mph

  Max. Traction Force

  7,342  kgf

  3330.27  lbf

  Max. Gradeability

  30  deg

  30  deg

  Bucket Digging Force (ISO)

  5,710  kgf

  2590.01  lbf

  Arm Digging Force (ISO)

  3,875  kgf

  1757.67  lbf

• Dimensions

  Overall Length

  6,310  mm

  20'8"  ft.in

  Overall Width

  2,250  mm

  7'5"  ft.in

  Overall Height

  2,780  mm

  9'1"  ft.in

  Tail Swing Radius

  1,930  mm

  6'4"  ft.in

  Tumbler Distance

  -

  Ground Clearance

  367  mm

  1'2"  ft.in

• Operating Range

  Boom Length

  3,722  mm

  12'3"  ft.in

  Arm Length

  1,620  mm

  5'4"  ft.in

  Max. Digging Reach

  6,290  mm

  20'8"  ft.in

  Max. Digging Depth

  4,070  mm

  13'4"  ft.in

  Max. Digging Height

  7,050  mm

  23'2"  ft.in

  Max. Dumping Height

  5,070  mm

  16'8"  ft.in

  Min. Swing Radius

  1,930  mm

  6'4"  ft.in
