Specifications

• General

  Type

  Compact Excavators

  Operating Weight

  5.48  ton

  12081.33  lb

  Bucket Capacity

  0.15  m³

  0.2  yd³

• Engine

  Emission

  STAGE V

  Engine model

  YANMAR 4TNV86CT

  YANMAR 4TNV86CT

  Rated Power

  47.6  hp / 2,400 rpm

  35.46  kw / 2,400 rpm

  Max. Torque

  18  kgf·m / 1,560 rpm

  130.15  lbf.ft / 1,560 rpm

• Hydraulic System

  Main Pumps Rated Flow

  138  ℓ/min

  138  ℓ/min

  Implement Circuit

  254  kgf/cm²

  3612.74  psi

• Tank Capacity

  Fuel Tank

  125  ℓ

  33.05  gal

  Hydraulic Tank

  44  ℓ

  11.63  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  10.1  rpm

  10.1  rpm

  Travel Speed

  4.7  km/h

  2.92  mph

  Max. Traction Force

  5,662  kgf

  2568.24  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  4,340  kgf

  1968.59  lbf

  Arm Digging Force (ISO)

  2,744  kgf

  1244.66  lbf

• Dimensions

  Overall Length

  5,490  mm

  18'0"  ft.in

  Overall Width

  2,000  mm

  6'7"  ft.in

  Overall Height

  2,555  mm

  8'5"  ft.in

  Tail Swing Radius

  1,175  mmZ

  3'10"  ft.inZ

  Tumbler Distance

  2,000  mm

  6'7"  ft.in

  Ground Clearance

  608  mm

  1'12"  ft.in

• Operating Range

  Boom Length

  2,800  mm

  9'2"  ft.in

  Arm Length

  1,400  mm

  4'7"  ft.in

  Max. Digging Reach

  5,990  mm

  19'8"  ft.in

  Max. Digging Depth

  3,500  mm

  11'6"  ft.in

  Max. Digging Height

  5,570  mm

  18'3"  ft.in

  Max. Dumping Height

  3,860  mm

  12'8"  ft.in

  Min. Swing Radius

  2,540  mm

  8'4"  ft.in
