Excavators
Type
Compact Excavators
Operating Weight
18.6  ton
Emission
TIER 2
Rated Power
126  hp / 2,100 rpm
General
Type
Compact Excavators
Operating Weight
18.6  ton
Bucket Capacity
0.76  m³
Engine
Emission
TIER 2
Engine model
MITSUBISHI S6S-DT
Rated Power
126  hp / 2,100 rpm
Max. Torque
42.5  kgf·m / 1,500 rpm
Hydraulic System
Main Pumps Rated Flow
2x160  ℓ/min
Implement Circuit
350  kgf/cm²
Tank Capacity
Fuel Tank
270  ℓ
Hydraulic Tank
160  ℓ
Performance
Swing Speed
11  rpm
Travel Speed
5.5  km/h
Max. Traction Force
17,000  kgf
Max. Gradeability
30  deg
Bucket Digging Force (ISO)
12,600  kgf[13680]kgf
Arm Digging Force (ISO)
8,190  kgf[8890]kgf
Dimensions
Overall Length
8,650  mm
Overall Width
2,850  mm
Overall Height
2,990  mm
Tail Swing Radius
2,530  mm
Tumbler Distance
3,360  mm
Ground Clearance
460  mm
Operating Range
Boom Length
5,100  mm
Arm Length
2,600  mm
Max. Digging Reach
9,020  mm
Max. Digging Depth
6,060  mm
Max. Digging Height
8,840  mm
Max. Dumping Height
6,220  mm
Min. Swing Radius
3,170  mm
- These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog. - The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
