Specifications

• General

  Type

  Medium Excavators

  Operating Weight

  21.2  ton

  46738.01  lb

  Bucket Capacity

  1.2  m³

  1.57  yd³

• Engine

  Emission

  ~TIER 2

  Engine model

  CUMMINS 6BT5.9-C

  CUMMINS 6BT5.9-C

  Rated Power

  140  kW / 2,000 rpm

  187  hp / 2,000 rpm

  Max. Torque

  57.6  kgf·m / 1,600 rpm

  416.49  lbf.ft / 1,600 rpm

• Hydraulic System

  Main Pumps Rated Flow

  2x220  ℓ/min

  2x220  ℓ/min

  Implement Circuit

  330  kgf/cm²

  4693.72  psi

• Tank Capacity

  Fuel Tank

  340  ℓ

  89.89  gal

  Hydraulic Tank

  150  ℓ

  39.66  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  11  rpm

  11  rpm

  Travel Speed

  5.3  km/h

  3.29  mph

  Max. Traction Force

  21,100  kgf

  9570.8  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  15,700  kgf

  7121.4  lbf

  Arm Digging Force (ISO)

  12,600  kgf

  5715.26  lbf

• Dimensions

  Overall Length

  9,610  mm

  31'6"  ft.in

  Overall Width

  2,800  mm

  9'2"  ft.in

  Overall Height

  2,920  mm

  9'7"  ft.in

  Tail Swing Radius

  2,845  mm

  9'4"  ft.in

  Tumbler Distance

  3,370  mm

  11'1"  ft.in

  Ground Clearance

  480  mm

  1'7"  ft.in

• Operating Range

  Boom Length

  5,680  mm

  18'8"  ft.in

  Arm Length

  2,400  mm

  7'10"  ft.in

  Max. Digging Reach

  9,477  mm

  31'1"  ft.in

  Max. Digging Depth

  6,236  mm

  20'6"  ft.in

  Max. Digging Height

  9,242  mm

  30'4"  ft.in

  Max. Dumping Height

  6,466  mm

  21'3"  ft.in

  Min. Swing Radius

  3,680  mm

  12'1"  ft.in
