Specifications

• General

  Type

  Compact Excavators

  Operating Weight

  2.685  ton

  5919.41  lb

  Bucket Capacity

  0.07  m³

  0.09  yd³

• Engine

  Emission

  STAGE V

  Engine model

  Kubota D1305

  Kubota D1305

  Rated Power

  24.85  hp / 2,400 rpm

  18.51  kw / 2,400 rpm

  Max. Torque

  8.30  kgf·m / 1,900 rpm

  60.01  lbf.ft / 1,900 rpm

• Hydraulic System

  Main Pumps Rated Flow

  138  ℓ/min

  138  ℓ/min

  Implement Circuit

  254  kgf/cm²

  3612.74  psi

• Tank Capacity

  Fuel Tank

  30  ℓ

  7.93  gal

  Hydraulic Tank

  27  ℓ

  7.14  gal

  DEF/ ADBLUE Tank

  -

• Performance

  Swing Speed

  9.16  rpm

  9.16  rpm

  Travel Speed

  4.35  km/h

  2.7  mph

  Max. Traction Force

  2,266  kgf

  1027.84  lbf

  Max. Gradeability

  35  deg

  35  deg

  Bucket Digging Force (ISO)

  2,079  kgf

  943.02  lbf

  Arm Digging Force (ISO)

  1,451  kgf

  658.16  lbf

• Dimensions

  Overall Length

  4,150  mm

  13'7"  ft.in

  Overall Width

  1,534  mm

  5'0"  ft.in

  Overall Height

  2,452  mm

  8'1"  ft.in

  Tail Swing Radius

  775  mm

  2'7"  ft.in

  Tumbler Distance

  1,550  mm

  5'1"  ft.in

  Ground Clearance

  328  mm

  1'1"  ft.in

• Operating Range

  Boom Length

  2,120  mm

  6'11"  ft.in

  Arm Length

  1,424  mm

  4'8"  ft.in

  Max. Digging Reach

  3,910  mm

  12'10"  ft.in

  Max. Digging Depth

  2,240  mm

  7'4"  ft.in

  Max. Digging Height

  3,730  mm

  12'3"  ft.in

  Max. Dumping Height

  2,670  mm

  8'9"  ft.in

  Min. Swing Radius

  1,580  mm

  5'2"  ft.in
